AudioControl EPICFOUR EPIC Series 4-Channel Amplifier
AudioControl EPICFOUR EPIC Series 4-Channel Amplifier
The AudioControl EPIC Series 4-Channel Amplifier delivers top-quality sound in a compact, thermally efficient design. Engineered with a high-current Class D design, itβs 2Ξ© stable, ensuring maximum power output while maintaining efficiency. With a smart auto-reset protection circuit and solid power/speaker terminals secured by hex screws, the EPIC Series amplifier offers reliable, exceptional sound quality in a rugged, space-saving package.
Features
- Compact High-Power Class D Amplifier
- High-Current Design β 2Ξ© Stable
- 4 x 100 Watts @ 4 ohms
- 4 x 200 Watts @ 2 ohms
- 2 x 400 Watts @ 4 ohms Bridged
- Smart Auto-Reset Protection Circuit
- 12 dB/octave Linkwitz-Riley Variable High Pass Filters
- Solid Power/Speaker Terminals with Hex Screws
Specifications
INPUTS
Line-Level Inputs: 500mV β 12V RMS
OUTPUTS - Continuous Power (RMS) @ 14.4V
4 x 100 Watts @ 4 Ohms
4 x 250 Watts @ 2 Ohms
2 x 400 Watts @ 1 Ohm
Remote Level Control
Included
Weights & Dimensions
6.1β³ W x 5.9β³ L x 2.01β³ H
Performance
Frequency Response (+/- 1 dB): 10 Hz β 22 kHz
S/N Ratio: 90.1 dBa, Ref 100 Watts @ 4 ohms
Power / Ground Wire Gauge: 4 AWG
Recommended Fuse Rating: 80 Amps
High Pass Filter: 12dB/octave Linkwitz-Riley, Off, 50 Hz to 500 Hz
Speaker Terminal Wire Gauge: 8 AWG
